Description
SR MEZZO SPECS
- neck type
- SRMD4 Maple neck
- top/back/body
- Poplar body
- fretboard
- Maple fretboardBlack dot inlay
- fret
- Medium frets
- number of frets
- 22
- bridge
- B10 bridge
- string space
- 19mm
- neck pickup
- Dynamix P neck pickupPassive
- bridge pickup
- Dynamix J bridge pickupPassive
- equaliser
- Ibanez Custom Electronics 2-band EQ
- factory tuning
- 1G,2D,3A,4E
- strings
- D’Addario® EXL165
- string gauge
- .045/.065/.085/.105
- nut
- Plastic
- hardware color
- Chrome
-
NECK DIMENSIONS
-
- Scale :
- 812mm/32″
- a : Width
- 38mm at NUT
- b : Width
- 61mm at 22F
- c : Thickness
- 19.5mm at 1F
- d : Thickness
- 21.5mm at 12F
- Radius :
- 305mmR
-
DESCRIPTION
-
-
CONTROLS
DESCRIPTION
-
FREQUENCY RESPONSE
DESCRIPTION
-
OTHER FEATURES
- Recommended Case
- WB250C
- 32 inch scale
Features
B10 Bridge
The B10 bridge allows fully adjustable intonation and solid tuning stability.
Dynamix pickups
Electronics consist of an Ibanez Custom Electronics 2-band EQ and an Ibanez DXP neck pickup and DXJ bridge pickup for extra punch.
32″ Scale Neck
The SR Mezzo’s 32” scale neck is 2” shorter than that of the general Ibanez SR models, but the Mezzo stills delivers a powerful low end.
